    6x4 Shacman F3000 Tractor Head Truck 11.596 L 280kw / 380hp Engine Power

    Ask Lasest Price
    Brand Name : SHAMCN F3000
    Model Number : SX4255
    Certification : ISO & CCC
    Price : USD 38000 ~ 59000 / UNIT
    Payment Terms : T/T, L/C
    Supply Ability : 2000 UNITS / MONTH
    Delivery Time : 10 ~ 30 working days
    • Product Details
    • Company Profile

    6x4 Shacman F3000 Tractor Head Truck 11.596 L 280kw / 380hp Engine Power

    Shacman F3000 6x4 TRACTOR TRAILER TRUCK

    F3000 / F2000 / M3000 / X3000 / H3000 Cabin Right Hand Drive

    380HP WEICHAI EURO2 ENGINE

    Optional Cummins Engine


    Vehicle Description
    Overall dimensions (mm)6635×2500×3700
    GVW (kg)25000
    Curb weight (kg)9000
    Max speed (km/h)100
    Chassis Description
    Chassis modelSX4255
    CabF2000 flat Roof cab,with A/C,RHD
    Wheel base (mm)2900+1400
    Front/Rear overhang (mm)1525/835
    EngineEngine typeWP12.380E32
    Emission levelEuro II
    Maximum power280kw (380hp) at 2200 rpm
    Maximum torque1600N.m at 1500-1800rpm
    Number of cylinders6
    Displacement (lit)11.596
    SystemWater cooled, turbocharged, air cooled, with EGR
    ClutchPlate's diameter¢430mm
    Operating systemHydraulic control with air booster, pulling
    Gear boxType12JSD180T -Manual
    Number of gears12 forward gears & 2 reverse
    Brake system

    Full air brake system, split pneumatic circuit;

    parking spring brake acting on rear axles, exhaust brake,

    AxleFront (T)MAN 7.5T
    Rear (T)STR 13T ,Double reduction driven axle
    Tire specification12.00R20
    SuspensionFront8-leaf spring
    Rear12-leaf spring
    BatteryVoltage (V)24
    Capacity (A.h)165×2
    FuelTypeFuel tank with lockable cap
    Capacity (L)380
