    6 Cbm T King Concrete Mixer Truck 4100 MM Wheelbase Yuchai 130 Hp Engine

    Ask Lasest Price
    Brand Name : SUNY
    Model Number : SYCMT6TKING
    Certification : CCC, ASME, BV, SGS, etc
    Price : USD 9, 000 ~ 27, 000 per Unit
    Payment Terms : L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 700 Units per year
    Delivery Time : 10 ~ 15 working days
    • Product Details
    • Company Profile

    6 Cbm T King Concrete Mixer Truck 4100 MM Wheelbase Yuchai 130 Hp Engine


    6 Cbm T King concrete mixer trucks 4100 MM Wheelbase Yuchai 130 Hp Engine


    Concrete mixing truck features


    1. The whole truck is convenient and stable with strong intensity

    2. Special purpose chassis is specially developed for rural market, even narrow country road can

    be easily handled.

    3. Steel structure adopts high - strength steel shot blasting, structure strength improved 20 % , strong

    bearing capacity and great anti - knock effects.

    4. Optimized design of concrete mixing tank, improve loading ability, mixing on average without separation.

    5. Mixing blade adopt three - dimensional double helix mixing design, reducing remnant rate to 0 . 6 % ,

    better than international standard 2 % , leading the industry standard 0 . 7 % - 1 %

    6. The blade has unique wear - resisting protection structure, improving blade service life 80 %

    7. The design of low angle of inclination, center of gravity is lower 5 % than similar concrete mixing truck,

    safety factor higher 10 % .

    8. Feeding inlet and discharging outlet with reasonable design, faster feeding and discharging,

    easy operation.


    Development strategy

    Strives for the survival by the quality, seek development by science and technology


    Corporate philosophy

    People - oriented, science and technology enterprise, recruiting high level scientific and

    technological personnel, actively introduce advanced technology at home and abroad


    Product Description


    6 Cbm T King Cement Mixer Truck 4100 MM Wheelbase Yuchai 130 Hp Engine


    Whole machine performanceItemUnit6 m3
    Chassis Model-T King ZB3160TPE3F
    Demissionmm7025 * 2285 * 3570
    wheel basemm4100
    Chassis configurationTurning form-Hydraulic power steering
    Service brake-Air - brake
    Parking braking-Air brake braking
    tyre-900 - 20
    EngineModel-

    YC4D130 - 41

    Turbocharged Intercooled

    Type-forced circulation cooler
    Powerkw96
    Max. standard rotate speedr / min3200
    Concrete mixing tankgeometric volumem310
    Rated mixing volumem36
    Feeding speedm3≥ 0 . 1
    Discharging speedm3≥ 0 . 8
    Max . rotated speedr / min0 - 15
    Driving systemHydraulic pump-Huayou High - pressure
    Radiator-24V Air - cooling
    Water supply systemSupply mode-air pressure supply




    1. Factory Supply:
    a. one of the biggest special using truck manufacturers in China,
    b. more than 300 kinds of special truck for your needing,

    2. OEM Ability:
    can produce according to your demand, the size, the color and the logo is optional for you.

    3. Good Quality:
    a. has solid technology, advanced equipment: reliant quality and flexible modes of operation also have strict quality control system
    b. passed the ISO9001 - 2008 and the 3C ( China Compulsory Certification )
    c. our brand is China famous brand with good reputation in the market.

    4. Good Service:
    24 – hour hotline and email

    5. Fast Delivery:
    10 - 15 days after payment, safe and quick delivery

    6. Standard Steering:
    Left – hand drive, if you need Right – hand drives, please inform us, we will make special order for you.

    We highly recommend this refrigerated truck. It ‘ s in an excellent condition and also with good quality and competitive price. Further information, pls feel free to contact with me or visit our website, we will offer our best service.

    Packaging & Shipping

    Truck is nude packing, shipping in container, in bulk, in ro – ro.

    We will choose the best shipping type basis on truck volume, truck structure, Sail Schedule, clients ’ requirement for clients!

    Company Information

    1. We are professional manufacturers for the special vehicles. We can supply all brands of special trucks, such as (beiben), Faw, Foton, Shaanxi, Sinotruck, JAC, JMC, DONGFENG.
    2. Our annual turnover has increased to 1.5 billion USD.
    3. The annual truck export amount ranks top 10 in China.
    4. Our main business includes producing special trucks and selling chassis, trucks and trucks' spare parts.


    More photo:
