    Dongfeng 2 cbm -3 cbm water tank Fire Fighting Vehicle , Jinka Cab 90hp

    Ask Lasest Price
    Brand Name : SUNY
    Model Number : SY5301SS
    Certification : CCC, ASME, BV, SGS, etc
    Price : USD12000 /set- USD35000/set
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 200 set per month
    Delivery Time : 15-25 working days
    • Product Details
    • Company Profile

    Dongfeng 2 cbm -3 cbm water tank Fire Fighting Vehicle , Jinka Cab 90hp

    Dongfeng 2 cbm -3 cbm water tank fire fighting Truck , Jinka Cab 90hp


    Description & application:


    1-It can do rescue job.

    2-It can do transport job

    3-it can do sanitation job



    Competitive Advantage:


    1- strict quality control ---- stable quality for each truck
    2- powful R & D capabilities ---- we can design and produce the truck according to different fire equipment of different countries so that it can be fit for different countries’ demand.
    3- best service ----- we cherish each customer and opportunity.


    Dongfeng 2 cbm -3 cbm water tank fire fighting Truck , Jinka Cab 90hp

    Vehicle Description
    Type4*2 water truckOverall dimensions(mm)5820*1940*2080
    GVW (kg)6495Mass in working order (kg)2850
    Fact cubage3.5Max speed (Km/h)95
    Chassis Description
    CabSingleChassis ModEQ1060TJ20D3
    Allowable Passengers In Cab3Air conditionerOptional
    Wheel base(mm)3300Number of axles2
    F/R track base(mm)1506/1466F/R overhang(mm)1032/1488
    Approach/Departure angle(°)19/15Spring plate8/9+5,6/8+4
    F/R axle-load2595/3900Type of fuelDiesel
    Tire specification7.00-16Tire quantity6
    Traction system4*2Operation control systemAir braking
    Braking systemSteering wheelElectric system24V
    Engine Description
    Engine modelYC4F90-30
    Exhaust/output2659/66Horse power90
    Engine ManufacturerGuangxi Yuchai Machinery Co., Ltd.
    Up-parts Description
    Tank Dimensions(mm)2400*1200*800
    Tank Description

    1. Shape:oalv

    2. Material:carbon steel4214


    3.Thickness:5mm

    All water truck can be make water wagon for transporting drinkinrg wate.

    Standard Equipment

    Equipped with front,rear, side sprinkler (sprinkling width>14m )

    Equipped with rear working platform with water cannon which can be turned all-round

    (range>28m),can be adjusted into flinging, heavy rain,light rain,drizzle model,

    with security barrier.

    Equipped with Hangzhou Weilong pump(suction lift>6m)

    Equipped with fire valve, water valve, and filter gauze

    Optional Equipment

    Shower ,pneumatic valve,Honda pump,tool box

    Optional other tire model

    Production cycle7-15 days
