    HOWO Road Synchronous Chip Sealer 6000L With ZZ1257M4641W Chassis

    HOWO Road Synchronous Chip Sealer 6000 L Asphalt Tank And 10000 L Chip Bucket ( Intelligent Model )


    Description:

    Chip and Spray

    It is one of the most successful road-resurfacing methods, designed to extend the life of a road’s driving surface. The chip seal process involves applying a layer of asphalt emulsion and aggregate rock over the road. The process consists of liquid asphalt, immediately followed by rock chips.

    It can perform asphalt binder spraying and chip spreading processes synchronously, which allows full contact between binders and aggregates, thus resulting in maximum cohesive performance. It can also separately spray or spread asphalt or aggregate in special conditions.


    Applications:

    1. The vehicle can be widely used in synchronous seal operation of each grade of highway. It is cost-saving, wear-resisting, anti-skidding and waterproof.
    2. After construction traffic can be quickly restored. It is suitable for waterproof of road surface and bridge deck, crushed stone seal technology of the lower seal coat and pavement maintenance and repairing.
    3. Chip Sealer can perform asphalt binder spraying and chip spreading processes synchronously, which allows full contact between binders and aggregates, thus resulting in maximum cohesive performance. It can also separately spray or spread asphalt or aggregate in special conditions.


    Specifications:

    Truck chassis specification

    Item

    unit

    parameter

    Chassis model


    ZZ1257M4641W

    Overall dimensions

    mm

    10250x2500x3650

    GVW

    kg

    Appro×25000

    Mass in working order

    Appro×17370

    Wheel base

    mm

    4600+1350

    Exhaust/hp

    ml/hp

    9726/290

    Max speed

    km/h

    90

    Tire specification

    12.00-20

    Engine type

    WD615.87

    Traction system

    6×4

    transmission

    10 speed with over drive and 2 reverse

    Number of axles

    3

    Electric system

    24 V

    Operation control system

    Electrically hydraulic control

    Allowable passengers in cab

    2

    gear box description

    Mechanical gear box 10 speeds + 2 rear

    Engine

    The truck, diesel engine, water cooled, direct injection, 270 horse power


    Special function

    Specification

    (intelligent models)

    Asphalt tank Total Volume ( L )

    6000

    Chippings bucket Total Volume( L )

    10000

    Insulating layer thickness ( mm )

    80

    Hydraulic pump

    50-20-16

    Proportional valve

    Taiwan EFBG-03-160-HF

    Asphalt pump

    QGB680

    Hydraulic motor for asphalt pump

    05-130-BD31

    Heating System

    Italian burner Riello ( G20 )

    Heat-transfer oil pump

    40-25-160

    Control System

    SIEMENS CLW-32-01

    Generator

    5.5 KW gasoline engine generator

    Number of nozzle

    32

    Spray medium

    Hot asphalt/ Hot modified asphalt/ Cutback asphalt/ Emulsified asphalt

    Spray width ( m )

    4

    Spray amount( L / m2 )

    0.3-3.5
