    Water Tank / Dry Powder Fire Fight Truck With Double Row / Air Braking

    Ask Lasest Price
    Brand Name : SUNY
    Model Number : SY5121XFIZ
    Certification : CCC, ASME, BV, SGS, etc
    Price : USD35000 /set- USD55000/set
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 200 set per month
    Delivery Time : 15-25 working days
    • Product Details
    • Company Profile

    Water Tank / Dry Powder Fire Fight Truck With Double Row / Air Braking

    ISUZU 2000 L Double Row Small Water Tank Fire Fighting Truck 4X2 2 Axle 90 Hp


    Description & application:
    1- Water tank fire truck equipped with water storage tank, fire pumps, fire fighting water cannon, and other fire equipment to put out the fire. It also can be absorb water directly and supply water to other fire vehicle, equipment or water supply shortage region. It is suitable for general fire put out.
    2- Water and foam fire truck water tank equipped with fire pump and foam mixed system, bubble gun, cannon, and etc., can spray water and foam mixture to put out the fire during extigushing. It is specially suitalbe in petrochemical industry, power plants and valuable equipment instruments, it is the necessaary fire truck for petrochemical enterprises, oil terminals, airport and city fire extigushing field.
    3- There are Dry powder fire truck and Ladder fire truck optional

    Competitive Advantage:
    1- powful R & D capabilities ---- we can design and produce the truck according to different fire equipment of different countries so that it can be fit for different countries’ demand.
    2- strict quality control ---- stable quality for each truck
    3- competitive price ----- based on same product, our price is most competitive
    4- best service ----- we cherish each customer and opportunity.

    Specifications:


    ISUZU 2000 L Double Row Small Water Tank Fire Fighting Truck 4X2 2 Axle 90 Hp


    Product

    Fire truck

    Vehicle

    description

    Overall dimensions(mm)

    6205*1900*2700

    GVW (kg)

    6510

    Mass in working order(kg)

    2050

    Rated loading capacity(kg)

    4085

    chassis

    parameters

    Chassis mod

    NKR77LLLWCJAY

    Fact cubage(L)

    2000L

    Water tanker dimension(mm)

    1100*1750*1100

    Approach/Departure angle(°)

    24/13

    F/R overhang(mm)

    1015/1830

    Wheel base(mm)

    3360

    F/R track base(mm)

    1504/1425

    Traction system

    4*2

    Number of axles

    2

    F/R axle-load(Kg)

    1810/4700

    Spring plate

    8/6+5

    Braking system

    Air braking

    Tire specification

    7.00-16

    Number of tires

    6+1

    Electric system

    24 v

    Allowable passengers in cab

    2+3

    Air-conditioner

    optional


    Engine

    Engine model

    4KH1-TC

    Type of fuel

    Diesel

    Exhaust(ml)

    2999

    Rated Power(kw)

    96

    Horse power

    131

    Operation control system

    Steering wheel

    transmission

    MSB

    Max speed(km/h)

    90

    Manufacturer

    Qingling Motors Co., LTD

    Emission standard

    EURO 3

    Equipment

    Water tanker: 9000L Foam tanker :1000L

    Middle and low pressure pump :CB20.10/30.60

    Flow:middle pressure 30L/S low pressure 60L/S

    Pressure: middle pressure 2.0MPa low pressure 1.0MPa

    PL48 Fire Pump Flow: 48L/S

    Pressure: 1.0~1.2MPa

    Fire distance (water):≥65m

    Production cycle

    15-20 days

    Warranty

    12 month, from the date of supply
