Brand Name : | SUNY |
Model Number : | ZN1041A5ZM |
Certification : | CCC, ASME, BV, SGS, etc |
Price : | USD 15000-20000 / Set |
Supply Ability : | 50 sets per month |
Delivery Time : | 25 days after receiving deposits |
4 X 2 Light Duty 3 Ton Refrigerated Box Truck Dongfeng Cooling Van Truck
Product Description:
Product Parameter:
Type | 4 * 2 refrigerated van truck |
Brand | Dongfeng |
Emission Standard | Euro 4 |
Cab | Single row, with A/C |
Vehicle Description | |
Overall dimensions(mm) | 5995 * 2100 * 3050 |
G.V.W (kg) | 7350 |
Curb weight(vehicle) (kg) | 4495 |
Loading capacity (kg) | 3000 |
Whole vehicle main performance | |
Max speed (Km/h) | 95 |
Engine | |
Engine model | ZD30D13-4N |
Maximum power (kw) | 96kw / 130hp |
Displacement (lit) | 2953 |
Number of cylinders | 4 |
Type of fuel | Diesel |
Chassis Description | |
Chassis model | ZN1041A5ZM |
Wheel base (mm) | 3360 |
F / R overhang (mm) | 1605 / 1575 |
F / R tread (mm) | 1568 / 1458 |
Gear box | 6 forwards & 1 reverse |
Spring plate | 6 / 5+ 5 |
Type of fuel | Diesel |
Brake system | Air braking |
Operation control system | Power Steering |
Electric system | 24V |
Tires & Quantity | 7.50R16 & 6+1 |
The Description for Refrigerated | |
Dimension (mm) | 4000 * 1800 * 1750 |
Fact volume (M3) | 15 |
Material | The fiber-glass between the inner-outer color plate |
Independent refrigeration unit | Equipped with the K693 independent refrigerated unit |
Temperature range | -10°C |
Heat preservation layer | 8cm |
Side door | For your optional |
The standard parts of van | Stainless lock,stainless cornerite,stainless frame,dome light,bumper block,ventilating slot |
![]() |
