    Professional High Pressure Foam Fire Fighting Vehicle 3 Axles DONGFENG 10000L

    Ask Lasest Price
    Brand Name : SUNY
    Model Number : SY5159XFSC
    Certification : CCC, ASME, BV, SGS, etc
    Price : USD55000 /set- USD75000/set
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 200 set per month
    Delivery Time : 15-25 working days
    • Product Details
    • Company Profile

    Professional High Pressure Foam Fire Fighting Vehicle 3 Axles DONGFENG 10000L

    Professional High Pressure Foam Fire Truck 3 Axles DONGFENG 10000L


    Description & application:
    1- Water tank fire truck equipped with water storage tank, fire pumps, fire fighting water cannon, and other fire equipment to put out the fire. It also can be absorb water directly and supply water to other fire vehicle, equipment or water supply shortage region. It is suitable for general fire put out.
    2- Water and foam fire truck water tank equipped with fire pump and foam mixed system, bubble gun, cannon, and etc., can spray water and foam mixture to put out the fire during extigushing. It is specially suitalbe in petrochemical industry, power plants and valuable equipment instruments, it is the necessaary fire truck for petrochemical enterprises, oil terminals, airport and city fire extigushing field.
    3- There are Dry powder fire truck and Ladder fire truck optional

    Competitive Advantage:
    1- powful R & D capabilities ---- we can design and produce the truck according to different fire equipment of different countries so that it can be fit for different countries’ demand.
    2- strict quality control ---- stable quality for each truck
    3- competitive price ----- based on same product, our price is most competitive
    4- best service ----- we cherish each customer and opportunity.

    Specifications:


    DONGFENG 10000L Water and Foam Fire Fighting Trucks 210hp 3 Axles


    Vehicle summary

    DongfengEQ5208GXF double rear axle fire truck widely used for public security,fire brigade,urban construction,sanitary and other fields,be able to fully meet the needs of different areas

    type

    Dongfeng EQ5208GXF double rear axle fire truck


    chassis


    EQ1208GJ5

    6x4

    weight parameter

    (kg)

    Load weight

    10000

    Overall dimensions (mm)

    9550×2500×3400

    Curb weight

    11650



    MAX overall weight

    21650

    Wheelbase (mm)

    4325+1350

    engine

    Model

    EQB210-20


    /

    Power/Displacement(kw/ml)

    155(210HP)/5880

    Factory

    DONGFENG GUMMINS

    Performance

    parameter

    Max speed (km/h)

    90

    Track span

    (mm)

    Front axle

    1940

    Max creeping slope capacity (%)

    25

    Rear axle

    1860

    Oil consumption/100K/L )

    28

    Reaching out of vehicle (mm)

    Front overhang

    1245

    Slope stop for empty vehicle (%)

    20

    Rear overhang

    2565

    Min circle turning Diameter (m)

    18

    Driving angle (°)

    Approach angle

    32

    Smallest ground clearance (mm)

    248

    Departure angle

    14

    cabin

    Straight head ,2 rows , 4 doors, allow 6 people

    Tire

    10.00-20

    Special function

    Flat head pure metal encloses type ,left hand drive .

    dedicated function

    Water capacity(L)

    9000L

    8000L

    Foam capacity(L)

    1000L

    2000L

    Fire-fighting cannon

    Type PP48Ddouble use

    Flow 48L/s/1.0MPa

    water throw range ≥60m/1.0MPa

    foam throw range ≥55m/1.0MPa

    Fire pump

    (Middle&low pressure flow)

    type CB20.10/30.60

    middle pressure flow 30L/S/2.0MPa

    Low pressure flow 60L/S/1.0MPa
